1310nm 1550nm Wavelength PLC Fiber Optic Splitter for Network FTTX Customized Length

1310nm 1550nm Wavelength PLC Fiber Optic Splitter for Network FTTX Customized Length
1310nm 1550nm Wavelength PLC Fiber Optic Splitter for Network FTTX Customized Length 1310nm 1550nm Wavelength PLC Fiber Optic Splitter for Network FTTX Customized Length 1310nm 1550nm Wavelength PLC Fiber Optic Splitter for Network FTTX Customized Length 1310nm 1550nm Wavelength PLC Fiber Optic Splitter for Network FTTX Customized Length 1310nm 1550nm Wavelength PLC Fiber Optic Splitter for Network FTTX Customized Length 1310nm 1550nm Wavelength PLC Fiber Optic Splitter for Network FTTX Customized Length

Large Image :  1310nm 1550nm Wavelength PLC Fiber Optic Splitter for Network FTTX Customized Length

Product Details:
Place of Origin: Hangzhou China
Brand Name: fiberspace
Model Number: Micro type splitters
Payment & Shipping Terms:
Minimum Order Quantity: 100 pieces
Price: $1.60 - $28.00/pieces
Contact Now

1310nm 1550nm Wavelength PLC Fiber Optic Splitter for Network FTTX Customized Length

Description
Type: PLC Splitter Use: FTTX
Warranty Time: 5 Years Network: Wired LAN
Length: Customizted Connector Type: SC FC
Wavelength: 1310nm/1490nm/1550nm Fiber Cable Type: PVC/LSZH

Products Description
• Low insertion loss,high return loss • Excellent Temperature stability • Good repeatability and exchangeability • Excellent mechanical endurance • Strict curing time and temperature control • Strict testing standards and methods for quality • Environment protection (ROHS Compliance) • The fiber optical patch cord can be customized according to customers'specific requirements (Customized Connector/Length/package.) • 100% NEW raw material and well quality control ensure the best life time.

Product Paramenters
Split Ratio
1:2
1:4
1：8
1：12
1：16
1：24
1：32
1：64
Insertion Loss (dB) Max
4.2
7.8
10.9
12.9
13.9
15.5
17.2
20.9
Loss Uniformity (dB) Max
0.6
0.7
1.0
1.2
1.2
1.5
1.5
2.0
PDL(dB) Max
0.3
Return Loss (dB) Min
≥ 55 dB (APC) ; ≥ 50 dB (PC / UPC)
Directivity (dB) Min
55
Splite Ratio
2:2
2:4
2:8
2:12
2:16
2:24
2:32
2:64
Insertion Loss (dB) Max
4.4
8.0
11.2
13.2
14.2
15.8
17.5
21.2
Loss Uniformity (dB) Max
0.6
0.7
1.0
1.2
1.2
1.5
1.5
2.0
PDL(dB) Max
0.3
Return Loss (dB) Min
≥ 55 dB (APC) ; ≥ 50 dB (PC / UPC)
Directivity (dB) Min
55
1310nm 1550nm Wavelength PLC Fiber Optic Splitter for Network FTTX Customized Length 0
If you have special needs of customized products, please contact us.
