Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks

Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks

Large Image :  Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks

Product Details:
Place of Origin: Hangzhou China
Brand Name: Fiberspace
Model Number: FSP-S9-24-LU
Payment & Shipping Terms:
Minimum Order Quantity: 100 units
Price: $13.00 - $40.00/units
Contact Now

Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks

Description
Type: Sub Optic Distribution Frame Use: FTTX
Warranty Time: 5 Years Network: ODN
Material: Cold Rolled Steel

Products Description
1. Reliable optical cable fixing device. 2. Standard 19 inch installation. 3. The splice tray can be flexibly expanded to meet the splicing of multi-core fiber optic cables. 4. Adjustable depth direction installation position.

Product Paramenters
Model
FSP-S9 Series
Size
24 Port (SC) : H×W×D = 44×482×270(MM)
48 Port (SC) : H×W×D = 88×482×270(MM)
Material
Cold Rolled Steel
Color
Gray (Default  RAL 7035) / Black / White
Splice Capacity
24~96 Cores
Adapter Type
SC / LC
Adaptor Capacity
24~96 Ports
Installation Method
Standard 19" Rack Mount

If you have special needs of customized products, please contact us.

Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 0
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 1
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 2
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 3
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 4
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 5
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 6
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 7
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 8
Related Products
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 9
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 10
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 11
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 12
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 13
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 14
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 15
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 16
Certifications
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 17
Company Introduction
Best 19 Inch LC UPC Optical Distribution Frame 24 Ports for Network and FTTH Networks 18
About Yuhua Tech Hangzhou Yuhua Technology Co., Ltd. is a high-tech enterprise founded in 2001, during the rapid development of China's FTTH construction it mainly provides solutions and products for domestic ODN construction, specialized in manufacturing ODN devices, such as Fiber adapters, Pigtails, Patchcords, ODB, ODF, and FDC, etc, especially is the largest manufacturer of FDC in the domestic market. With the development of many years formed an integrated enterprise possessing plastic injection production line, SMC shell production line, sheet metal production line, fiber polishing production line, etc, even covered all the processes of ODN products.Now it has a workshop area of about 27,000 square meters, a technical development team of more than 30 people, and more than 200 workers. Hangzhou Fiberspace Import & Export Co., Ltd is a subsidiary of Yuhua Tech, founded in 2020, possessing an experienced R&D team and Marketing team, Focus on providing cost-effective ODN product solutions for global users and bringing Yuhua's products to the world with the brand "Fiberspace". Welcome to our website： http://www.fiberspace.com.cn

FAQ Q:  Are you a manufacturer or trading company? A: We are an Origin factory. Like we mention in the company introduction ,we have two companies ,Yuhua tech & Fiberspace Import &Export,Fiberspace is a subsidiary of Yuhua tech(has been certified by Alibaba),focus on providing cost-effective ODN product solutions for global users and bringing Yuhua's products to the world with the brand "Fiberspace".
Q: Where is your factory located? How can I visit it? A: Our factory is located in No.9 Huan an road, Lishan Town, Fuyang District, Hangzhou City, Zhejiang Province. 40 Minutes by car from Hangzhou Airport.
Q: How can I get the sample? What's the lead time? A: By DHL/UPS/FedEx express. Samples lead time is 7-14 days.
Q: How does your factory control product quality? A: ISO9001 Certificated, independent quality control team with 20 inspectors in our factory. The third-party certificated and factory audit accepted.  Third-party quality control accepted.
Q: Do you provide ODM/OEM service? A: OEM/ODM is welcome, From the concept to finished goods, we have our own designer, do all in the factory.
