16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx

16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx
16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx

Large Image :  16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx

Product Details:
Place of Origin: Hangzhou China
Brand Name: Fiberspace
Model Number: FSP-P-16-Q
Payment & Shipping Terms:
Minimum Order Quantity: 100 pieces
Price: $10.00 - $12.00/pieces
Contact Now

16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx

Description
Type: Fiber Optic Distribution Box Use: FTTx
Warranty Time: 5 Years Network: Wired LAN
Material: PC+ABS Main Cable Port: 4 Ports
Drop Cable Port: 16 Ports Color: Gray

Products Description
1. For connection and distribution of fiber optic terminals. 2. Independent routing channels for easy maintenance and management. 3. Enclosed structure,excelent protection grade(IP65). 4. 4 incoming cable ports,uncut cable is possible,can support cables with no more than 12mm diameter 5. 16 outgoing dropcable ports,suitable for fast connectors.

Product Paramenters
Model
FSP-P-16-Q
Size
H×W×D = 285×180×100 (MM)
Material
PC+ABS
Color
White / Gray
Splice Capacity
16 Cores
Adapter Type
SC
Adaptor Capacity
16 Ports
Installation Method
Wall / Pole-mounted

If you have special needs of customized products, please contact us.

16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 0
16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 1
Related Products
16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 2
16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 3
16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 4
16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 5
16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 6
16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 7
16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 8
16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 9
Certifications
16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 10
Company Introduction
16 Port FTTH Fiber Optic Terminal Box IP65 Wall Pole Mount Outdoor Cajas for FTTx 11
About Yuhua Tech Hangzhou Yuhua Technology Co., Ltd. is a high-tech enterprise founded in 2001, during the rapid development of China's FTTH construction it mainly provides solutions and products for domestic ODN construction, specialized in manufacturing ODN devices, such as Fiber adapters, Pigtails, Patchcords, ODB, ODF, and FDC, etc, especially is the largest manufacturer of FDC in the domestic market. With the development of many years formed an integrated enterprise possessing plastic injection production line, SMC shell production line, sheet metal production line, fiber polishing production line, etc, even covered all the processes of ODN products.Now it has a workshop area of about 27,000 square meters, a technical development team of more than 30 people, and more than 200 workers. Hangzhou Fiberspace Import & Export Co., Ltd is a subsidiary of Yuhua Tech, founded in 2020, possessing an experienced R&D team and Marketing team, Focus on providing cost-effective ODN product solutions for global users and bringing Yuhua's products to the world with the brand "Fiberspace". Welcome to our website： http://www.fiberspace.com.cn

FAQ Q:  Are you a manufacturer or trading company? A: We are an Origin factory. Like we mention in the company introduction ,we have two companies ,Yuhua tech & Fiberspace Import &Export,Fiberspace is a subsidiary of Yuhua tech(has been certified by Alibaba),focus on providing cost-effective ODN product solutions for global users and bringing Yuhua's products to the world with the brand "Fiberspace".
Q: Where is your factory located? How can I visit it? A: Our factory is located in No.9 Huan an road, Lishan Town, Fuyang District, Hangzhou City, Zhejiang Province. 40 Minutes by car from Hangzhou Airport.
Q: How can I get the sample? What's the lead time? A: By DHL/UPS/FedEx express. Samples lead time is 7-14 days.
Q: How does your factory control product quality? A: ISO9001 Certificated, independent quality control team with 20 inspectors in our factory. The third-party certificated and factory audit accepted.  Third-party quality control accepted.
Q: Do you provide ODM/OEM service? A: OEM/ODM is welcome, From the concept to finished goods, we have our own designer, do all in the factory.
